1X743-12-12 43 Series 1X743

43 Series 1X743

Parkrimp Permanent Flange – 45° Elbow – Full flange system for Code 61 or Code 62

Part #: 1X743-12-12 Manufacturer: Parker
Price/UOM: $41.74In Stock!
Availability : Backordered

Parker 43 Series Fittings is a Parkrimp permanent (crimp) style fitting which permits quick assembly with our family of Parkrimp crimpers. Assembly of No-Skive hose and fittings does not require removal of the outer cover of the hose. This eliminates premature hose failure caused by skiving too long or short. 43 Series Fittings has Chromium-6 free plating and are used with Parker Hydraulic Braided, Light Spiral, Specialty, Suction and Return Hoses.

Product Attributes

End 1: 3/4 Inch
Inner Diameter: 0.75 Inch
Material: Cast Iron
Trade Name: Parkrimp
Series: 43
Configuration Type: Flange – 45° Elbow – Full flange system for Code 61 or Code 62
Inch/Metric: Inch
End 1 Type: Inch
Hose Connection Type: Permanent
Inner Diameter Inch/mm: Inch
Parker Division: Hose Products
Parker Group: Fluid Connector
